The Open Pluggable Specification (OPS) is the industry standard for connecting computer devices to large flat panel/interactive displays via a single universal 80 Pin JAE internal slot. With no need for any cables, the OPS System simply plugs into a single slot in the back of any OPS compatible display (both touch and non-touch), instantly converting your big screen into a giant all-in-one Windows PC.

Opc PC module for Interactive Flat Panel

Applicable panel Brands: Promethean Activpanel, Smart Boards, HITACHI, CTOUCH, SHARP, BENQ, Geneeworld, Newline interative, TEAMBOARD, TRIUMPH BOARD.

Specification

Processor	Intel^®Core 8^thi3/i5/i7 CPU
Chipsets	SOC
Memory	4GB DDR4 2400MHz Max.32GB
Storage	128G SSD(1x 2.5")
	1x M.2 SSD(Blank)
Graphics	Intel^® UHD620 Graphics
Wireless	802.11g /n/ac
Network	Intel Gigabit Ethernet
Audio	Realtek ALC662 HD
Interfaces	1x DP out
	1x HDMI out (3840x2160)
	1x Type-C
	4x USB3.0 Type-A
	1x USB2.0 Type-A
	1x RJ45 10/100/1000M
	1x 3.5mm Line out
	1x 3.5mm Mic in
	1x Power button
	1x Reset button
	1x Onekey recovery button
	2x WIFI ANT
JAE 80pin	Compliant

Power input	DC 12V~19V
Power consumption	30W
Watchdog	Support
Material	Metal
Dimensions	18011930mm
Temperature	Operdting -5℃~45℃
	Storage -20℃~70℃
Relative humidity	10%~95% (non-condensing)

Weight	1.1kg
