Optical parts

Lens

F=1.4-2.6;f=3.9-39mm

Zoom

10X Optical ,10X Digital zoom

Display area

Maximum 320×240 mm

Focus

Auto

Aperture

Auto

Imaging system

Shooting

1/3'' Color  5.0 mega pixel imaging system

SNR

>50db

White balance

Auto

Image processing function

Image freezing, mirror image,Black & white / color switching

Lighting part

Fill-light lamp

High-flux LED  illumination>800LUX

Input option

VGA Switch

Local/External VGA

Input terminal

VGA

D-SUB 15 Pin socket×1

Output terminal

VGA

D-SUB 15Pin socket×1

HDMI

HDMI 19pin socket×1

USB

SLAVER USB× 1

VGA System

Output resolution

1280X1024@60HZ , 1280X720@60HZ，1024Ⅹ768@60HZ

Horizontal definition

≥1000TV Line

Controlling method

Control panel, remote control

Operating conditions

Power supply

DC12V 2A

Power consumption

≤24W

Temperature

0℃～40℃
