Product Introduction
1. Super narrow design, frame width 10.6mm, thickness 5.8mm, work with all kinds of ATM and small size LED/LCD screen,
2. Aluminum frame with oxidation processing
3. Dual touch, no need drivers, plug and play；
4. High precision/ resolutions.
5. Work perfectly under the sunlight
6. Equipped with 2.5mm tempered glass, work perfectly under the harsh environment.
7. Work with system Windows7/ 8/10、Windows XP、Linux、Vista、Android
Specification：
|
Size range |
15'(4:3/16:9)', 15.6'', 17''(4:3), 18.5''(16:9), 19''(5:4/16:10), 21.5''(16:9) |
|
Touch Technology |
Infrared |
|
Touch point |
Dual Touch |
|
Touch medium |
the finger (wear gloves, finger), touch pen or other opaque media |
|
Minimum touch object |
≥5 mm |
|
Touch precision |
2 mm |
|
Touch times |
Over 60,000,000 times single spot touch |
|
Touch Resolution |
32768x32768 |
|
Transmittance |
AR glass 92%, tempered glass 90%, up to 100% of the maximum (no glass) |
|
The response speed |
less than 5 ms |
|
Drive mode |
without drive, plug and play |
|
Interface mode |
USB2.0 |
|
Operating voltage |
USB 5V DC (4.75V DC ~ 5.25V DC) |
|
Working power |
less than 1 W |
|
Frame material |
aluminum alloy surface oxidation |
|
Frame color |
black |
|
Frame Width |
10.6mm |
|
Frame thickness |
5.8mm |
|
Glass |
2.5mm tempered glass |
|
Working temperature |
-10 ~ 60 ℃ |
|
Working humidity |
10% ~ 85%RH, no condensation |
|
Application |
ATM machine, Information Kiosk |
